User Manual - Karaoke Party Speaker

Getting started

To make correct use of the functions and to know the system’s connections and usage, please read this user manual carefully before using the product. Keep this manual in a safe place for future reference.

Introduction

• Connection: Bluetooth, TF card, USB, FM and 6.35mm Dynamic Micro Input.
• Built-in recharging battery.
• Do not expose to direct heat, flame or submerge in water.
• Do not use your product in wet, hot, damp or excessively humid conditions.

Package list

• Speaker
• Wireless microphones
• USB charging cable (loudspeaker and microphones share one cable)
• User manual

Panel functions

• M - Switch between Bluetooth, USB, TF card and AUX
• ⏯ - Play / Pause
• ⏪ - Previous song
• ⏩ Next song
• 💡- Short-press: Play / Pause | Long-press: Change microphone volume

DC 5V Power

Connect to charge your speaker.

Play via TF Card

Insert the TF Card into the slot to play music from the card.

USB

Insert a USB memory stick into the slot and any MP3 format music can be played directly.

Specifications

• Wireless - V5.2
• Working Distance - 10M
• Battery - Speaker: 3.7V / 1200mAh, Mics: 2 x 3,7V / 400mAh
• Speaker - 4”
• Output Power - 10W
• Frequency Response - 60Hz-20KHz
• Bluetooth name - PartyFunLights
