User Manual - Wireless Headphone

Getting Started

To make correct use of the functions and to know the system’s connections and usage, please read this user manual carefully before using the product. Keep this manual in a safe place for future reference.

Button Operation Instructions

(I)/📞 - Press the key three seconds for power on/off.

⏯ - During the music playing ,click once to play/pause music.

(I)/📞 - When receiving a call, click once to answer, press two seconds to reject. Double click to redial the last number .

 ⏮️ /V- - Press quickly to listen to your previous song. Press and hold to decrease volume level.

⏭ /V+ - Press quickly to listen to your next song. Press and hold to increase volume level.

LED Indicator

• The blue light will flash fast during pairing state. When the headphone is successfully connected to the phone the blue light will burn continuously.
• If the battery is low, the indicator light will become red.
• In charging mode, the red light will burn steadily while charging. It takes around 2 hours to charge the battery. The red light will turn off, when the battery is fully charged

External Input

When the headphone is turned on, plug-in an audio 3.5mm audio cable, and it will turn to AUX / LINE IN.

Wireless Connect

Wireless Connect pairing automatically starts when you turn on the headphone. Make sure to turn on the Bluetooth on your device as well and choose the Bluetooth device “PartyFunLights” for a wireless connection with the Headphone. Once connected with your device, the flashing blue light will change in a constant blue light.

Specifications

Built-in battery - 300mAh

Limited charge voltage - DC 5.0~5.25V

Charging time - 0.5-1.5h

Playing time - 4-6h

Calling time - 4-6h

Sensitivity - 102dB±3dB

Drive units - Ø40mm

Frequency response - 20-20000Hz

Rated power - 10mW

Max power - 50mW

Wireless Connect distance - 0-10m

Wireless Connect version - bt5.0

Wireless Connect solution - Jieli
